5mW Laser Module Emitter - Red Line

CAUTION: Class III, avoid direct eye exposure to beams.
SKU: 100061
Availability: Out of Stock - on backorder and will be dispatched once in stock.
R0,00
:

Description

CAUTION: Class III, avoid direct eye exposure to beams.

Features

  • Output power: Min 2.5mW, Typical 3.0mW, Max 5.0mW
  • Working current: Min 10mA, Typical 20mA, Max 25mA
  • Working voltage: Min 2.3VDC, Typical 4.5VDC, Max 8.0VDC
  • Wavelength: 650nm
  • Working temperature: Min -15C, Typical 25C, Max 35C
  • Storage temperature: Min -20C, Max +25C
  • Focused dot width: <2mm spotting 3 meters away
  • Practical test for point head: reflection visible to random target >1000m
